塑膠系列橋式TKP型、TKP型MW規格、TKP型加長自由跨距規格、TKP型旋轉規格

鏈節
縮短、延長

標準電纜保護鏈條，尺寸範圍從小到大。
·它是最常用且易於使用的。
加長自由跨距規格、旋轉規格以及其他各種特殊規格。
·MW規格利用滑動性高的材料，具有防止電纜軟管外膜磨損的效果。

特性

TKP型

豐富的尺寸

從小尺寸到大尺寸共16種。
塑膠，輕便，經濟實惠
易於拼接

將銷軸插入孔中的簡單連接結構，便於切斷及連接。
支持多層隔斷

TKP35H22至TKP125H74 (部分尺寸除外) 可將收納空間分成多個部分，提高佈局的自由度。
鋼制的固定件也可以變更為不鏽鋼制。
在保持品質的基礎上，增加了對環境的考慮

TKP形的部分尺寸改用環保再生材料，在保持與以往相同的性能、尺寸、外觀的同時，
實現更環保的產品制造。

TKP型MW規格

低塵

與 TKP 型相比，電纜保護鏈條和電纜/軟管滑動產生的磨損粉較少，電纜保護鏈條連接部件滑動產生的磨損粉也較少。
近似尺寸和結構與TKP型相同

特殊規格

TKP型加長自由跨距規格

這是一種使用方法，當需要超過能力曲線圖上自由跨度的長行程時，電纜保護鏈條會在導軌上滑動。
- 透過安裝滑橇，可實現長行程和高速運動，從而延長使用壽命並節省人工。

通過降低運行成本，為降低總成本和環境負荷做贡獻。

TKP型旋轉規格

·可用於旋轉運動的設備。
·不能使用標準品。是特殊制作品。

查看詳細規格

關於其他的特殊規格請參照這裡。

產品目錄、使用說明書

商品一覽表

※單擊以查看詳細信息。全部開啟全部關閉

纜線軟管最大外徑4mm、7mm、8mm (TKP13~，TKP17~)

纜線・軟管最大外徑 mm	間距 mm	內高 mm	內寬 mm	彎曲半徑 mm	臂開合結構
4	13	10	6	20	TKP13H10-20W6R20	TKP13H10-30W6R20	---	---	---	---	---	---	---
28	TKP13H10-20W6R28	TKP13H10-30W6R28
37	TKP13H10-20W6R37	TKP13H10-30W6R37
7	17	11	10	17	---	TKP17H11-30W10R17	---	---	---	---	---	---	---
8	13	10	10	18	---	TKP13H10-30W10R18TC	TKP13H10-30W10R18M	---	---	---	---	---	---
20	TKP13H10-20W10R20	---	---
28	TKP13H10-20W10R28	TKP13H10-30W10R28TC	TKP13H10-30W10R28M
37	TKP13H10-20W10R37	TKP13H10-30W10R37TC	TKP13H10-30W10R37M
15	20	TKP13H10-20W15R20	TKP13H10-30W15R20	---	---	---	---	---	---	---
28	TKP13H10-20W15R28	TKP13H10-30W15R28
37	TKP13H10-20W15R37	TKP13H10-30W15R37
20	18	---	TKP13H10-30W20R18TC	TKP13H10-30W20R18M	---	---	---	---	---	---
20	TKP13H10-20W20R20	---	---
28	TKP13H10-20W20R28	TKP13H10-30W20R28TC	TKP13H10-30W20R28M
37	TKP13H10-20W20R37	TKP13H10-30W20R37TC	TKP13H10-30W20R37M

電纜軟管最大外徑11mm、12mm、13mm、14mm、20mm (TKP18~，TKP25~，TKP35~)

纜線・軟管最大外徑 mm	間距 mm	內高 mm	內寬 mm	彎曲半徑 mm	臂開合結構
11	35	22	13	37	---	TKP35H22-30W13R37	TKP35H22-30W13R37M	---	TKP35H22-40W13R37	TKP35H22-40W13R37M	---	---	---
50	TKP35H22-30W13R50	TKP35H22-30W13R50M	TKP35H22-40W13R50	TKP35H22-40W13R50M
75	TKP35H22-30W13R75	TKP35H22-30W13R75M	TKP35H22-40W13R75	TKP35H22-40W13R75M
100	TKP35H22-30W13R100	TKP35H22-30W13R100M	TKP35H22-40W13R100	TKP35H22-40W13R100M
12	18	14	15	28	---	TKP18H14-30W15R28TC	TKP18H14-30W15R28M	---	---	---	---	---	---
37	TKP18H14-30W15R37TC	TKP18H14-30W15R37M
50	TKP18H14-30W15R50TC	TKP18H14-30W15R50M
40	28	---	TKP18H14-30W40R28TC	TKP18H14-30W40R28M	---	---	---	---	---	---
37	TKP18H14-30W40R37TC	TKP18H14-30W40R37M
50	TKP18H14-30W40R50TC	TKP18H14-30W40R50M
13	15	15	28	TKP18H15-20W15R28	---	---	---	---	---	---	---	---
37	TKP18H15-20W15R37
50	TKP18H15-20W15R50
20	28	TKP18H15-20W20R28	TKP18H15-30W20R28	---	---	---	---	---	---	---
37	TKP18H15-20W20R37	TKP18H15-30W20R37
50	TKP18H15-20W20R50	TKP18H15-30W20R50
30	28	TKP18H15-20W30R28	TKP18H15-30W30R28	---	---	---	---	---	---	---
37	TKP18H15-20W30R37	TKP18H15-30W30R37
50	TKP18H15-20W30R50	TKP18H15-30W30R50
40	28	TKP18H15-20W40R28	---	---	---	---	---	---	---	---
37	TKP18H15-20W40R37
50	TKP18H15-20W40R50
25	15	15	28	---	TKP25H15-30W15R28	TKP25H15-30W15R28M	---	---	---	---	---	---
37	TKP25H15-30W15R37	TKP25H15-30W15R37M
50	TKP25H15-30W15R50	TKP25H15-30W15R50M
20	28	---	TKP25H15-30W20R28	TKP25H15-30W20R28M	---	---	---	---	---	---
37	TKP25H15-30W20R37	TKP25H15-30W20R37M
50	TKP25H15-30W20R50	TKP25H15-30W20R50M
30	28	---	TKP25H15-30W30R28	TKP25H15-30W30R28M	---	---	---	---	---	---
37	TKP25H15-30W30R37	TKP25H15-30W30R37M
50	TKP25H15-30W30R50	TKP25H15-30W30R50M
14	35	32	16	48	---	TKP35H32-30W16R48	---	---	---	---	---	---	---
60	TKP35H32-30W16R60	TKP35H32-30W16R60M
75	TKP35H32-30W16R75	TKP35H32-30W16R75M
100	TKP35H32-30W16R100	TKP35H32-30W16R100M
125	TKP35H32-30W16R125	TKP35H32-30W16R125M
20	35	22	25	37	---	TKP35H22-30W25R37	TKP35H22-30W25R37M	TKP35H22-30W25R37	TKP35H22-40W25R37	TKP35H22-40W25R37M	---	---	---
50	TKP35H22-30W25R50	TKP35H22-30W25R50M	TKP35H22-30W25R50	TKP35H22-40W25R50	TKP35H22-40W25R50M
75	TKP35H22-30W25R75	TKP35H22-30W25R75M	TKP35H22-30W25R75	TKP35H22-40W25R75	TKP35H22-40W25R75M
100	TKP35H22-30W25R100	TKP35H22-30W25R100M	TKP35H22-30W25R100	TKP35H22-40W25R100	TKP35H22-40W25R100M
38	37	---	TKP35H22-30W38R37	TKP35H22-30W38R37M	TKP35H22-30W38R37	TKP35H22-40W38R37	TKP35H22-40W38R37M	---	---	---
50	TKP35H22-30W38R50	TKP35H22-30W38R50M	TKP35H22-30W38R50	TKP35H22-40W38R50	TKP35H22-40W38R50M
75	TKP35H22-30W38R75	TKP35H22-30W38R75M	TKP35H22-30W38R75	TKP35H22-40W38R75	TKP35H22-40W38R75M
100	TKP35H22-30W38R100	TKP35H22-30W38R100M	TKP35H22-30W38R100	TKP35H22-40W38R100	TKP35H22-40W38R100M
50	37	---	TKP35H22-30W50R37	TKP35H22-30W50R37M	TKP35H22-30W50R37	TKP35H22-40W50R37	TKP35H22-40W50R37M	---	---	---
50	TKP35H22-30W50R50	TKP35H22-30W50R50M	TKP35H22-30W50R50	TKP35H22-40W50R50	TKP35H22-40W50R50M
75	TKP35H22-30W50R75	TKP35H22-30W50R75M	TKP35H22-30W50R75	TKP35H22-40W50R75	TKP35H22-40W50R75M
100	TKP35H22-30W50R100	TKP35H22-30W50R100M	TKP35H22-30W50R100	TKP35H22-40W50R100	TKP35H22-40W50R100M
63	37	---	TKP35H22-30W63R37	TKP35H22-30W63R37M	TKP35H22-30W63R37	TKP35H22-40W63R37	TKP35H22-40W63R37M	---	---	---
50	TKP35H22-30W63R50	TKP35H22-30W63R50M	TKP35H22-30W63R50	TKP35H22-40W63R50	TKP35H22-40W63R50M
75	TKP35H22-30W63R75	TKP35H22-30W63R75M	TKP35H22-30W63R75	TKP35H22-40W63R75	TKP35H22-40W63R75M
100	TKP35H22-30W63R100	TKP35H22-30W63R100M	TKP35H22-30W63R100	TKP35H22-40W63R100	TKP35H22-40W63R100M

纜線軟管最大外徑22mm, 29mm (TKP35~，TKP45~)

纜線・軟管最大外徑 mm	間距 mm	內高 mm	內寬 mm	彎曲半徑 mm	臂開合結構
22	45	25	38	50	---	TKP45H25-30W38R50	TKP45H25-30W38R50M	TKP45H25-30W38R50	TKP45H25-40W38R50	TKP45H25-40W38R50M	---	---	---
75	TKP45H25-30W38R75	TKP45H25-30W38R75M	TKP45H25-30W38R75	TKP45H25-40W38R75	TKP45H25-40W38R75M
95	TKP45H25-30W38R95	TKP45H25-30W38R95M	TKP45H25-30W38R95	TKP45H25-40W38R95	TKP45H25-40W38R95M
125	TKP45H25-30W38R125	TKP45H25-30W38R125M	TKP45H25-30W38R125	TKP45H25-40W38R125	TKP45H25-40W38R125M
150	TKP45H25-30W38R150	TKP45H25-30W38R150M	TKP45H25-30W38R150	TKP45H25-40W38R150	TKP45H25-40W38R150M
200	TKP45H25-30W38R200	TKP45H25-30W38R200M	TKP45H25-30W38R200	TKP45H25-40W38R200	TKP45H25-40W38R200M
58	50	---	TKP45H25-30W58R50	TKP45H25-30W58R50M	TKP45H25-30W58R50	TKP45H25-40W58R50	TKP45H25-40W58R50M	---	---	---
75	TKP45H25-30W58R75	TKP45H25-30W58R75M	TKP45H25-30W58R75	TKP45H25-40W58R75	TKP45H25-40W58R75M
95	TKP45H25-30W58R95	TKP45H25-30W58R95M	TKP45H25-30W58R95	TKP45H25-40W58R95	TKP45H25-40W58R95M
125	TKP45H25-30W58R125	TKP45H25-30W58R125M	TKP45H25-30W58R125	TKP45H25-40W58R125	TKP45H25-40W58R125M
150	TKP45H25-30W58R150	TKP45H25-30W58R150M	TKP45H25-30W58R150	TKP45H25-40W58R150	TKP45H25-40W58R150M
200	TKP45H25-30W58R200	TKP45H25-30W58R200M	TKP45H25-30W58R200	TKP45H25-40W58R200	TKP45H25-40W58R200M
78	50	---	TKP45H25-30W78R50	TKP45H25-30W78R50M	TKP45H25-30W78R50	TKP45H25-40W78R50	TKP45H25-40W78R50M	---	---	---
75	TKP45H25-30W78R75	TKP45H25-30W78R75M	TKP45H25-30W78R75	TKP45H25-40W78R75	TKP45H25-40W78R75M
95	TKP45H25-30W78R95	TKP45H25-30W78R95M	TKP45H25-30W78R95	TKP45H25-40W78R95	TKP45H25-40W78R95M
125	TKP45H25-30W78R125	TKP45H25-30W78R125M	TKP45H25-30W78R125	TKP45H25-40W78R125	TKP45H25-40W78R125M
150	TKP45H25-30W78R150	TKP45H25-30W78R150M	TKP45H25-30W78R150	TKP45H25-40W78R150	TKP45H25-40W78R150M
200	TKP45H25-30W78R200	TKP45H25-30W78R200M	TKP45H25-30W78R200	TKP45H25-40W78R200	TKP45H25-40W78R200M
103	50	---	TKP45H25-30W103R50	TKP45H25-30W103R50M	TKP45H25-30W103R50	TKP45H25-40W103R50	TKP45H25-40W103R50M	---	---	---
75	TKP45H25-30W103R75	TKP45H25-30W103R75M	TKP45H25-30W103R75	TKP45H25-40W103R75	TKP45H25-40W103R75M
95	TKP45H25-30W103R95	TKP45H25-30W103R95M	TKP45H25-30W103R95	TKP45H25-40W103R95	TKP45H25-40W103R95M
125	TKP45H25-30W103R125	TKP45H25-30W103R125M	TKP45H25-30W103R125	TKP45H25-40W103R125	TKP45H25-40W103R125M
150	TKP45H25-30W103R150	TKP45H25-30W103R150M	TKP45H25-30W103R150	TKP45H25-40W103R150	TKP45H25-40W103R150M
200	TKP45H25-30W103R200	TKP45H25-30W103R200M	TKP45H25-30W103R200	TKP45H25-40W103R200	TKP45H25-40W103R200M
35	32	25	48	---	TKP35H32-30W25R48	---	---	TKP35H32-40W25R48	---	---	---	---
60	TKP35H32-30W25R60	TKP35H32-40W25R60
75	TKP35H32-30W25R75	TKP35H32-40W25R75
100	TKP35H32-30W25R100	TKP35H32-40W25R100
125	TKP35H32-30W25R125	TKP35H32-40W25R125
29	35	32	38	48	---	TKP35H32-30W38R48	---	---	TKP35H32-40W38R48	---	---	---	---
60	TKP35H32-30W38R60	TKP35H32-40W38R60
75	TKP35H32-30W38R75	TKP35H32-40W38R75
100	TKP35H32-30W38R100	TKP35H32-40W38R100
125	TKP35H32-30W38R125	TKP35H32-40W38R125
50	48	---	TKP35H32-30W50R48	---	---	TKP35H32-40W50R48	---	---	---	---
60	TKP35H32-30W50R60	TKP35H32-40W50R60
75	TKP35H32-30W50R75	TKP35H32-40W50R75
100	TKP35H32-30W50R100	TKP35H32-40W50R100
125	TKP35H32-30W50R125	TKP35H32-40W50R125

纜線軟管最大外徑30mm, 35mm (TKP58~，TKP62~)

纜線・軟管最大外徑 mm	間距 mm	內高 mm	內寬 mm	彎曲半徑 mm	臂開合結構
30	62.5	34	150	75	---	---	---	---	---	---	---	TKP62H34W150R75	TKP62H34W150R75
90	TKP62H34W150R90	TKP62H34W150R90
125	TKP62H34W150R125	TKP62H34W150R125
150	TKP62H34W150R150	TKP62H34W150R150
200	TKP62H34W150R200	TKP62H34W150R200
200	75	---	---	---	---	---	---	---	TKP62H34W200R75	TKP62H34W200R75
90	TKP62H34W200R90	TKP62H34W200R90
125	TKP62H34W200R125	TKP62H34W200R125
150	TKP62H34W200R150	TKP62H34W200R150
200	TKP62H34W200R200	TKP62H34W200R200
35	58	39	50	60	---	TKP58H39-30W50R60	---	TKP58H39-30W50R60	TKP58H39-40W50R60	---	---	---	---
75	TKP58H39-30W50R75	TKP58H39-30W50R75	TKP58H39-40W50R75
90	TKP58H39-30W50R90	TKP58H39-30W50R90	TKP58H39-40W50R90
125	TKP58H39-30W50R125	TKP58H39-30W50R125	TKP58H39-40W50R125
150	TKP58H39-30W50R150	TKP58H39-30W50R150	TKP58H39-40W50R150
200	TKP58H39-30W50R200	TKP58H39-30W50R200	TKP58H39-40W50R200
75	60	---	TKP58H39-30W75R60	---	TKP58H39-30W75R60	TKP58H39-40W75R60	---	---	---	---
75	TKP58H39-30W75R75	TKP58H39-30W75R75	TKP58H39-40W75R75
90	TKP58H39-30W75R90	TKP58H39-30W75R90	TKP58H39-40W75R90
125	TKP58H39-30W75R125	TKP58H39-30W75R125	TKP58H39-40W75R125
150	TKP58H39-30W75R150	TKP58H39-30W75R150	TKP58H39-40W75R150
200	TKP58H39-30W75R200	TKP58H39-30W75R200	TKP58H39-40W75R200
100	60	---	TKP58H39-30W100R60	---	TKP58H39-30W100R60	TKP58H39-40W100R60	---	---	---	---
75	TKP58H39-30W100R75	TKP58H39-30W100R75	TKP58H39-40W100R75
90	TKP58H39-30W100R90	TKP58H39-30W100R90	TKP58H39-40W100R90
125	TKP58H39-30W100R125	TKP58H39-30W100R125	TKP58H39-40W100R125
150	TKP58H39-30W100R150	TKP58H39-30W100R150	TKP58H39-40W100R150
200	TKP58H39-30W100R200	TKP58H39-30W100R200	TKP58H39-40W100R200
125	60	---	TKP58H39-30W125R60	---	TKP58H39-30W125R60	TKP58H39-40W125R60	---	---	---	---
75	TKP58H39-30W125R75	TKP58H39-30W125R75	TKP58H39-40W125R75
90	TKP58H39-30W125R90	TKP58H39-30W125R90	TKP58H39-40W125R90
125	TKP58H39-30W125R125	TKP58H39-30W125R125	TKP58H39-40W125R125
150	TKP58H39-30W125R150	TKP58H39-30W125R150	TKP58H39-40W125R150
200	TKP58H39-30W125R200	TKP58H39-30W125R200	TKP58H39-40W125R200

纜線軟管最大外徑41mm, 45mm (TKP68~，TKP90~)

纜線・軟管最大外徑 mm	間距 mm	內高 mm	內寬 mm	彎曲半徑 mm	臂開合結構
41	68	46	75	75	---	TKP68H46-30W75R75	---	TKP68H46-30W75R75	TKP68H46-40W75R75	---	---	---	---
100	TKP68H46-30W75R100	TKP68H46-30W75R100	TKP68H46-40W75R100
125	TKP68H46-30W75R125	TKP68H46-30W75R125	TKP68H46-40W75R125
150	TKP68H46-30W75R150	TKP68H46-30W75R150	TKP68H46-40W75R150
200	TKP68H46-30W75R200	TKP68H46-30W75R200	TKP68H46-40W75R200
250	TKP68H46-30W75R250	TKP68H46-30W75R250	TKP68H46-40W75R250
100	75	---	TKP68H46-30W100R75	---	TKP68H46-30W100R75	TKP68H46-40W100R75	---	---	---	---
100	TKP68H46-30W100R100	TKP68H46-30W100R100	TKP68H46-40W100R100
125	TKP68H46-30W100R125	TKP68H46-30W100R125	TKP68H46-40W100R125
150	TKP68H46-30W100R150	TKP68H46-30W100R150	TKP68H46-40W100R150
200	TKP68H46-30W100R200	TKP68H46-30W100R200	TKP68H46-40W100R200
250	TKP68H46-30W100R250	TKP68H46-30W100R250	TKP68H46-40W100R250
125	75	---	TKP68H46-30W125R75	---	TKP68H46-30W125R75	TKP68H46-40W125R75	---	---	---	---
100	TKP68H46-30W125R100	TKP68H46-30W125R100	TKP68H46-40W125R100
125	TKP68H46-30W125R125	TKP68H46-30W125R125	TKP68H46-40W125R125
150	TKP68H46-30W125R150	TKP68H46-30W125R150	TKP68H46-40W125R150
200	TKP68H46-30W125R200	TKP68H46-30W125R200	TKP68H46-40W125R200
250	TKP68H46-30W125R250	TKP68H46-30W125R250	TKP68H46-40W125R250
150	75	---	TKP68H46-30W150R75	---	TKP68H46-30W150R75	TKP68H46-40W150R75	---	---	---	---
100	TKP68H46-30W150R100	TKP68H46-30W150R100	TKP68H46-40W150R100
125	TKP68H46-30W150R125	TKP68H46-30W150R125	TKP68H46-40W150R125
150	TKP68H46-30W150R150	TKP68H46-30W150R150	TKP68H46-40W150R150
200	TKP68H46-30W150R200	TKP68H46-30W150R200	TKP68H46-40W150R200
250	TKP68H46-30W150R250	TKP68H46-30W150R250	TKP68H46-40W150R250
175	75	---	TKP68H46-30W175R75	---	TKP68H46-30W175R75	TKP68H46-40W175R75	---	---	---	---
100	TKP68H46-30W175R100	TKP68H46-30W175R100	TKP68H46-40W175R100
125	TKP68H46-30W175R125	TKP68H46-30W175R125	TKP68H46-40W175R125
150	TKP68H46-30W175R150	TKP68H46-30W175R150	TKP68H46-40W175R150
200	TKP68H46-30W175R200	TKP68H46-30W175R200	TKP68H46-40W175R200
250	TKP68H46-30W175R250	TKP68H46-30W175R250	TKP68H46-40W175R250
45	90	50	100	130	---	---	---	---	---	---	---	TKP90H50W100R130	TKP90H50W100R130
200	TKP90H50W100R200	TKP90H50W100R200
250	TKP90H50W100R250	TKP90H50W100R250
300	TKP90H50W100R300	---
150	130	---	---	---	---	---	---	---	TKP90H50W150R130	TKP90H50W150R130
200	TKP90H50W150R200	TKP90H50W150R200
250	TKP90H50W150R250	TKP90H50W150R250
300	TKP90H50W150R300	---
200	130	---	---	---	---	---	---	---	TKP90H50W200R130	TKP90H50W200R130
200	TKP90H50W200R200	TKP90H50W200R200
250	TKP90H50W200R250	TKP90H50W200R250
300	TKP90H50W200R300	---

纜線軟管最大外徑50mm (TKP91H56~)

纜線・軟管最大外徑 mm	間距 mm	內高 mm	內寬 mm	彎曲半徑 mm	臂開合結構
50	91	56	150	150	---	---	---	---	---	---	---	TKP91H56W150R150	---
200	TKP91H56W150R200	TKP91H56W150R200-GA
250	TKP91H56W150R250	TKP91H56W150R250-GA
300	TKP91H56W150R300	TKP91H56W150R300-GA
350	TKP91H56W150R350	---
400	TKP91H56W150R400	---
175	150	---	---	---	---	---	---	---	TKP91H56W175R150	---
200	TKP91H56W175R200	TKP91H56W175R200-GA
250	TKP91H56W175R250	TKP91H56W175R250-GA
300	TKP91H56W175R300	TKP91H56W175R300-GA
350	TKP91H56W175R350	---
400	TKP91H56W175R400	---
200	150	---	---	---	---	---	---	---	TKP91H56W200R150	---
200	TKP91H56W200R200	TKP91H56W200R200-GA
250	TKP91H56W200R250	TKP91H56W200R250-GA
300	TKP91H56W200R300	TKP91H56W200R300-GA
350	TKP91H56W200R350	---
400	TKP91H56W200R400	---
225	150	---	---	---	---	---	---	---	TKP91H56W225R150	---
200	TKP91H56W225R200	TKP91H56W225R200-GA
250	TKP91H56W225R250	TKP91H56W225R250-GA
300	TKP91H56W225R300	TKP91H56W225R300-GA
350	TKP91H56W225R350	---
400	TKP91H56W225R400	---
250	150	---	---	---	---	---	---	---	TKP91H56W250R150	---
200	TKP91H56W250R200	TKP91H56W250R200-GA
250	TKP91H56W250R250	TKP91H56W250R250-GA
300	TKP91H56W250R300	TKP91H56W250R300-GA
350	TKP91H56W250R350	---
400	TKP91H56W250R400	---
275	150	---	---	---	---	---	---	---	TKP91H56W275R150	---
200	TKP91H56W275R200	TKP91H56W275R200-GA
250	TKP91H56W275R250	TKP91H56W275R250-GA
300	TKP91H56W275R300	TKP91H56W275R300-GA
350	TKP91H56W275R350	---
400	TKP91H56W275R400	---
300	150	---	---	---	---	---	---	---	TKP91H56W300R150	---
200	TKP91H56W300R200	TKP91H56W300R200-GA
250	TKP91H56W300R250	TKP91H56W300R250-GA
300	TKP91H56W300R300	TKP91H56W300R300-GA
350	TKP91H56W300R350	---
400	TKP91H56W300R400	---
325	150	---	---	---	---	---	---	---	TKP91H56W325R150	---
200	TKP91H56W325R200	TKP91H56W325R200-GA
250	TKP91H56W325R250	TKP91H56W325R250-GA
300	TKP91H56W325R300	TKP91H56W325R300-GA
350	TKP91H56W325R350	---
400	TKP91H56W325R400	---
350	150	---	---	---	---	---	---	---	TKP91H56W350R150	---
200	TKP91H56W350R200	TKP91H56W350R200-GA
250	TKP91H56W350R250	TKP91H56W350R250-GA
300	TKP91H56W350R300	TKP91H56W350R300-GA
350	TKP91H56W350R350	---
400	TKP91H56W350R400	---
400	150	---	---	---	---	---	---	---	TKP91H56W400R150	---
200	TKP91H56W400R200	TKP91H56W400R200-GA
250	TKP91H56W400R250	TKP91H56W400R250-GA
300	TKP91H56W400R300	TKP91H56W400R300-GA
350	TKP91H56W400R350	---
400	TKP91H56W400R400	---
450	150	---	---	---	---	---	---	---	TKP91H56W450R150	---
200	TKP91H56W450R200	TKP91H56W450R200-GA
250	TKP91H56W450R250	TKP91H56W450R250-GA
300	TKP91H56W450R300	TKP91H56W450R300-GA
350	TKP91H56W450R350	---
400	TKP91H56W450R400	---
500	150	---	---	---	---	---	---	---	TKP91H56W500R150	---
200	TKP91H56W500R200	TKP91H56W500R200-GA
250	TKP91H56W500R250	TKP91H56W500R250-GA
300	TKP91H56W500R300	TKP91H56W500R300-GA
350	TKP91H56W500R350	---
400	TKP91H56W500R400	---

纜線軟管最大外徑67mm (TKP125~)

纜線・軟管最大外徑 mm	間距 mm	內高 mm	內寬 mm	彎曲半徑 mm	臂開合結構
67	125	74	150	185	---	---	---	---	---	---	---	TKP125H74W150R185	TKP125H74W150R185
250	TKP125H74W150R250	TKP125H74W150R250
350	TKP125H74W150R350	TKP125H74W150R350
450	TKP125H74W150R450	---
250	185	---	---	---	---	---	---	---	TKP125H74W250R185	TKP125H74W250R185
250	TKP125H74W250R250	TKP125H74W250R250
350	TKP125H74W250R350	TKP125H74W250R350
450	TKP125H74W250R450	---
350	185	---	---	---	---	---	---	---	TKP125H74W350R185	TKP125H74W350R185
250	TKP125H74W350R250	TKP125H74W350R250
350	TKP125H74W350R350	TKP125H74W350R350
450	TKP125H74W350R450	---

纜線軟管最大外徑72mm (TKP91H80~)

纜線・軟管最大外徑 mm	間距 mm	內高 mm	內寬 mm	彎曲半徑 mm	臂開合結構
					一體式	蓋板外周側開閉類型			蓋板內週側開閉類型			蓋板內週邊側開閉類型
					一體式	標準規格	MW規格	加長自由跨距規格	標準規格	MW規格	加長自由跨距規格	標準規格	加長自由跨距規格
4	13	10	6	20	TKP13H10-20W6R20	TKP13H10-30W6R20	---	---	---	---	---	---	---
				28	TKP13H10-20W6R28	TKP13H10-30W6R28
				37	TKP13H10-20W6R37	TKP13H10-30W6R37
7	17	11	10	17	---	TKP17H11-30W10R17	---	---	---	---	---	---	---
8	13	10	10	18	---	TKP13H10-30W10R18TC	TKP13H10-30W10R18M	---	---	---	---	---	---
				20	TKP13H10-20W10R20	---	---
				28	TKP13H10-20W10R28	TKP13H10-30W10R28TC	TKP13H10-30W10R28M
				37	TKP13H10-20W10R37	TKP13H10-30W10R37TC	TKP13H10-30W10R37M
			15	20	TKP13H10-20W15R20	TKP13H10-30W15R20	---	---	---	---	---	---	---
				28	TKP13H10-20W15R28	TKP13H10-30W15R28
				37	TKP13H10-20W15R37	TKP13H10-30W15R37
			20	18	---	TKP13H10-30W20R18TC	TKP13H10-30W20R18M	---	---	---	---	---	---
				20	TKP13H10-20W20R20	---	---
				28	TKP13H10-20W20R28	TKP13H10-30W20R28TC	TKP13H10-30W20R28M
				37	TKP13H10-20W20R37	TKP13H10-30W20R37TC	TKP13H10-30W20R37M

椿本產業機械產品 資訊網站

塑膠系列 橋式TKP型、TKP型MW規格、TKP型加長自由跨距規格、TKP型旋轉規格

特性

TKP型

TKP型MW規格

特殊規格

TKP型加長自由跨距規格

TKP型旋轉規格

產品目錄、使用說明書

商品一覽表

椿本產業機械產品資訊網站

塑膠系列橋式TKP型、TKP型MW規格、TKP型加長自由跨距規格、TKP型旋轉規格
